PE Plus Online Low Frequency UPS , Output PF 1.0 Uninterruptible Power Supply

PE Plus Online Low Frequency UPS , Output PF 1.0 Uninterruptible Power Supply supplier PE Plus Online Low Frequency UPS , Output PF 1.0 Uninterruptible Power Supply supplier PE Plus Online Low Frequency UPS , Output PF 1.0 Uninterruptible Power Supply supplier

Large Image :  PE Plus Online Low Frequency UPS , Output PF 1.0 Uninterruptible Power Supply

Product Details:

Place of Origin:SHENHZEN , CHINA
Brand Name:HRD OR OEM
Certification:CE
Model Number:PEII3310,PEII3320,PEII3330,PEII3340,PEII3360,PEII3380

Payment & Shipping Terms:

Minimum Order Quantity:5PCS
Price:USD 2300-8500USD/PCS
Packaging Details:wooden case t with pallet for export
Delivery Time:5-10 WORKING DAYS
Supply Ability:500PCS/MONTH
Detailed Product Description
Output PF: 1.0 Technology: SCR Rectifier With IGBT Inverter
Control: Fully Control With Double DSP SPS: Redundant Design To Ensure The System Working
Efficency: 92%, 2-3% Higher Than Traditional Design Dust Filter: Yes
Conformal Coating: Yes MTBF: ≧200000 Hours
MTBR: Full Front Access ,short Time ABM: YES
Parallel: Up To 8 Units Output Isolation: Yes, With Isolation Transformer

PE plus series Online LF UPS 10-80kVA , with output PF 1.0

PE II series is a fully DSP controlled high-level industry UPS with capacity up to 800kVA.
Based on nowadays the most advanced DSP(TI 2833X CPU), MCU, CPLD ect ,and more than 20nos leading innovative technology ,this UPS has become a perfect robust and cost-effective power solution, optimizing the minimal operating cost for end users.
Its extremely high reliability can solidly ensure the continuous availability of power and safe operations for all types of critical load.
Fully DSP technology with extremely low cycle current,it can be parallel up to 8 units for redundancy or capacity expanding purpose.
Super reliability and excellent performance based on innovational solution,it definitely ensures your business away from any power problem!

MAIN FEATURES:

  • World Leading technology
  • The state-of-art fully DSP online double conversion technology
  • Super wide input voltage/frequency range, adapt to harsh utility environments
  • Soft start with time settable 6-100seconds settable , more compatible with generator
  • Output power factor 0.9(1.0optional), and output short-tolerant capability
  • Intelligent self diagnosis, mass memory(1000 events) to record operation log
  • Super long MTBF≧200000 hours, and short MTTR
  • Intelligent parallel up to 8 units and parallel ECO Mode.
  • Most intelligent digital equal current parallel technology,self-load share algorithm
  • Single Mode ECO and parallel ECO available
  • Independent cooling system, muti-protection design, ensuring high reliability with kinds of harsh environments
  • Output short-tolerant ability,
  • ABM technology, extremely low ripple current to extend battery lifespan
  • Frequency convertor mode function
  • Emergency Power Off(EPO)
  • Super Reliability
  • Fully DSP control with output isolation transformer, super reliability.
  • Redundant SPS,fan etc. design, enhancing system reliability.
  • Build-in output isolation transformer, eliminate neutral to ground drifting voltage, and isolate load harmonic current influence to inverter.
  • Besides highest design technology,only qualified famous brand components used.
  • Conformal-coating PCB fixed in sealed box,keeping away from outside effect

3.Communication Interface

  • Build-in various communication connectors (RS232, RS485, AS400 etc).
  • PE Plus Online Low Frequency UPS , Output PF 1.0 Uninterruptible Power SupplyOptional cards available: SNMP, battery management kit, lighting proof module, dust proof filter etc.



  • Easy Operation
  • Front side maintenance, top or bottom wiring connection, with protective equipment.
  • Friendly human machine interface,with 7inch touch screen



PE Plus Online Low Frequency UPS , Output PF 1.0 Uninterruptible Power Supply
5.Perfect Application:

  • Small and middle Datacenters,
  • Server-rooms,Finance,Insurance,
  • Medical and Education equipment
  • Theater, Harbor, Traffic facilities,
  • Telecommunications,
  • Industrial Production etc.
Capacity10kVA15kVA20kVA30kVA40kVA50kVA60kVA80kVA
10kW15kW20kW30kW40kW50kW60kW80kW
InputWiring connectionThree phase+Ground
Nominal voltage380/400/415VAC
Voltage range285VAC~498VAC
Frequency50/60Hz
Frequency range45-65Hz
Soft start5-600sec settable
Power factor0.95(with input filter)
BypassNominal voltage380/400/415VAC (Three phase+Neutral+Ground)
Frequency50/60Hz±10%
Voltage range±10%,±15%,±20% settable
OutputNominal voltage380/400/415VAC (Three phase+Neutral+Ground)
Voltageregulation±1%(balance load),±2%(100% unbalance load)
Power factor0.9 or 1.0 optional
Dynamic response±5%(0~100% load transient)
Distortion<1%(100% linear load ),<3%(100% non-linear load)
Transient response<5ms
Sync. Range±2Hz(±0.5—±3Hz settable)
Overload105% continue,110% 1Hr,125% 10min,150% 1min
Frequency±0.05%
WaveformPure sine wave
EfficiencyInverter modeUp to 92%
ECO mode98%
ParallelN+XMax 8 units
BatteryConfigurtation12V,32 pieces default(30~34pieces settable)
DisplayLCD + LED
PhysicalDimension
(mm)
Depth720750
800
Width560800
Height11001400
N.W(Kg)195235255300315480480550
G.W (Kg)210250270315330510510580
EnvironmentTemperature0-40℃
Humidity0-95% non condensing
Noise(1m)67dB
ConnectiveRS-232/(USB option)Support windows2000/XP/7/Linux/Unix/Mac
SNMPSupport remote control through web browser
StandardAnti-thunderD grade
SaftyIEC60950-1,IEC62040-1-1
EMCIEC62040-2,IEC62040-3

Note: Without other notice if product parameters changed.
Customized according to customer requirement available.
