PC AMERICA True Sine Wave Rack Mount Ups 6kva 4U For Servers
Product Details:
| Place of Origin: | Shenzhen China |
| Brand Name: | OEM or ODM |
| Certification: | CE ,IS09001-2000 |
| Model Number: | PCA06R,PCA3108R,PCA3110R |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10PCS |
|---|---|
| Price: | 800-1500USD |
| Packaging Details: | 1PCS/CTN |
| Delivery Time: | 15-20DAYS |
| Payment Terms: | TT OR LC |
| Supply Ability: | 300pcs/day |
| Price term: | Fob shenzhen |
| Warranty: | 18months after shipment, 10years spares support |
|
Detail Information |
|||
| High Light: | rack ups systems,rack mounted ups,6kva 4U rack mount ups |
||
|---|---|---|---|
Product Description
PC AMERICA True Sine Wave Rack Mount Ups 6kva Double-Conversion For Servers
Quick Detail:
1, High Frequency On-line Ups 6-10kva
2, rack mount type
3, RS232+USB, SNMP optional
Introduction
Power Castle Rack mount Online HF UPS 4-10kva is a powerful product range with high adaptability and flexibility. It’s specially designed for 110/120/127vac 60hz power grid, such as in America and Japan. Its cut-edge digital control technology of DSP (Digital Signal Processor), can greatly improve the product performance and system reliability, and deliver a compact integration with higher power density.
Perfect Application:
Network, data centre, servers and workstations, control system, communication system and office etc.
Main Features are below:
19' Rack-mount, 4U(height)
High frequency and dual conversion on-line technology
192VDC and 240vdc easy convertible by jumpers
Perfect failure protection and alarm function:
Rich Communication and Monitoring Features
Large LCD display and easy maintenance design
Advanced PFC technology parallel technology(N+1)
Self-diagnosis when UPS startup
AC starts and Cold start function (DC power on )
Automatically charging batteries in UPS off mode
Lightning and surge protections (surge energy rating 1050 Joules)
4 levels Fan speed automatically changes as load varies
Technical Specifications
|
Model |
PCA06R |
PCA06RS |
PCA3108R |
PCA3108RS |
PCA3110R |
PCA3110RS |
|
Capacity(linear Load) |
6KVA/5.4KW |
8KVA/7.2KW |
10KVA/9KW |
|||
|
Phase |
1/1phase |
3/1phase |
||||
|
Input Voltage Range |
80V-148+/-5v |
155-260v+/-5v |
||||
|
Input Frequency Range |
40~70Hz |
|||||
|
Output Voltage |
110/120/127V±1.5% |
|||||
|
Output Frequency |
50/60Hz±5Hz(line mode), 50/60Hz±0.5Hz(battery mode) |
|||||
|
Output Voltage Tolerance |
<±5%(100% Load or without Load) |
|||||
|
Distortion |
<3%(Linear Load); <5%(Non-linear load) |
|||||
|
Output Waveform |
True Sine Wave |
|||||
|
Overload Capability |
105%~125%, 1Mins; 125%~150%30sec |
|||||
|
Battery Voltage |
192VDC(EXTERNAL) |
|||||
|
Charge Voltage |
220VDC |
|||||
|
Charge Current |
Standard model 1.5A ；Long back model 4A |
|||||
|
Battery Type |
Sealed Maintenance-Free Lead-Acid |
|||||
|
Batteries Q'TY |
16Pcs ×12VDC or 20pcs ×12VDC |
|||||
|
Standard Backup Time(Full Load/Half Load) |
5/12Mins |
|||||
