Power well series 3 Phase Online Ups 10-80kva 380 / 400 / 415vac For data centre

Power well series 3 Phase Online Ups 10-80kva 380 / 400 / 415vac For data centre supplier Power well series 3 Phase Online Ups 10-80kva 380 / 400 / 415vac For data centre supplier Power well series 3 Phase Online Ups 10-80kva 380 / 400 / 415vac For data centre supplier Power well series 3 Phase Online Ups 10-80kva 380 / 400 / 415vac For data centre supplier Power well series 3 Phase Online Ups 10-80kva 380 / 400 / 415vac For data centre supplier Power well series 3 Phase Online Ups 10-80kva 380 / 400 / 415vac For data centre supplier Power well series 3 Phase Online Ups 10-80kva 380 / 400 / 415vac For data centre supplier

Large Image :  Power well series 3 Phase Online Ups 10-80kva 380 / 400 / 415vac For data centre

Product Details:

Place of Origin:Shenzhen Guangdong
Brand Name:HRD/OEM/ODM
Certification:CE, ISO9001
Model Number:PW3320,PW3330, PW3340, PW3360,PW3380
Application:Data Center, Medium-scale network system etc.

Payment & Shipping Terms:

Minimum Order Quantity:10PCS
Price:2300-10000USD
Packaging Details:Standard for export
Delivery Time:3 weeks after down payment
Payment Terms:TT or LC at sight
Supply Ability:100pcs/ month
Price term:Fob Shenzhen
Warranty:2 years after shipment , with 10years technical support
Detailed Product Description

Power well series 3 Phase Online Ups 10-80kva 380 / 400 / 415vac For data centre



(10-40kva,200/208/220Vac 3-3phase , transformerless available)

Powerwell series 3 phase 10-80kva is a high end uninterruptible power supply, which has adopted  the world leading electrical and electronic technology to increase performance and super high reliability(MTBT>200,000h).3nos high speed DSPs with completed digital control fully  ensure highest quality of power supply. Being kin to 1.0 input power factor and less than 2% THDi lead this UPS green and energy saving. It also offers humanization design: full front access of service ability, user- friendly touch screen.

Perfect Applications:

Internet Servor ,Middle Data Center, Medium-scale network system / computing center, bank and securities, business server group, Medium-scale office automation, precision equipment, etc.

Features: complete digital control technology

Fully digital control with two DSPs, all the subsystems are digital controlled including the IGBT rectifier, inverter, charger, discharger.

Excellent electrical properties

True online double conversion struction offers the safe and effective power protection for various loads, with strong output load capacity

High input power factor, green and energy-saving

Input  with PFC and input PF of the whole UPS up to 0.99

Dual AC input source supportable

Allowable AC and bypass separate input ac source

Strong environmental adaptability

Wide input voltage and frequency range, adaptation to all kinds of power grid

and geographical environment

Comprehensive protection measures

 Surge Protection, short circuit protection, and other protection to ensure the reliability of UPS system

IGBT and SCR adopt the advanced EUPEC power module;

The adoption of advanced technology (IGBT driving technology, IGBT soft over-current shutdown,VCE protection)highly improves the reliability and safety of inverter.

Similar modular design

Each phase main board are designed like rack for easy assembling and maintenance

Inbuilt battery pack plug-in design for easy use

Intelligent battery management (ABM)

Adopting the intelligent battery management, extending battery lifespan extremely

Intelligent interval  three-stage charging process( constant current, constant voltage, float charging and charger shut off, when battery voltage decrease to a lower level, charger restarts to work)

Automatic temperature compensation,( -0.11% per °C ), to extremely extend battery life by 30% and minimize the maintaining work;

Power well series 3 Phase Online Ups 10-80kva 380 / 400 / 415vac For data centre

Online detecting battery status

The max battery charging current can set by end users according to the battery features, to avoid any damage caused by the big charging current;

Back up time displayed on the LCD screen

Periodic self-test battery, detecting the battery problems timely

With battery inverse connection, over voltage / current protection, to protect the battery

Cold start and AC start Function

Directly start the UPS through battery or start UPS through Mains only.

Superior network monitoring capabilities

Communication port (RS232, RS485, dry contact and so on) connecting with computer,SNMP card optional,

Easy-maintenance design(MMTM<0.5h)

a) Adopts the full front maintenance design, reducing the restrictions

on the installation space, and saving the space of computing center

b)Modular design class, convenient and easy site maintenance

c) With manual maintain bypass

d)Battery replacement without disrupting the UPS running

e) Historical records classified with search function, events up to1,000 items

Advanced parallel technology:

With digital control technology for cycle current control, parallel system with very high reliable and up to 6units. and sharing  common battery;

Friendly interface with Large LCD with multi language display(7 languages)

 Large LCD display and LED status indication; Abundant information display of UPS

English, Spanish, Portugese, Russion

Technical Specifications:





Model

PW3310

PW3315

PW3320

PW3330

PW3340

PW3360

PW3380

Rating Power

10Kva/9Kw

15Kva/13.5Kw

20Kva/18Kw

30Kva/27Kw

40Kva/36Kw

60Kva/54Kw

80Kva/72Kw

AC Input

Rated voltage

190/208/220Vac Or 380/400/415Vac(Line-Line)

Input connection

Three phase four wires

Power factor

Above 0.99

THDi

Less 3%

Voltage range

-40%~+25%

Frequency

40-70Hz

Bypass

+/- 15%(settable)

Output

Power factor

0.9 (lag)

voltage precision

190/208/220Vac Or 380/400/415Vac±0.5%

Dynamical

voltage transient

Less 5% ( 0~100% load step)

THDU

THD less 0.6%( linear load ),3%(non-linear load)

Crest Factor

3:1

Frequency

tracking range

50/60Hz±3Hz

Output

Frequency precision

±0.05%(Battery mode) , ±3hz(Line mode)

phase displacement

120±0.5°(Balance or imbalance load )

Voltage unbalance

+/-3%( 100% unbalance load)



Frequency

tracking rate

Less 1Hz/s

Overload capability

105% long time operation,  125%<Load<150%,transfer to bypass after 10 minutes

Above 150%, transfer to bypass after 200ms

Bypass overload

                                                      Below125%  long time operation

                                              125%<Load<150%,10mins;above 150% 1S

System

System efficiency

Above 94%(Normal  and battery mode)

98%(ECO mode)

Display

 Touch screen LCD+LED





EMC

IEC62040-2

IEC61000-4-2 (ESD)

IEC61000-4-3 (RS)

IEC6100-4-4 (EFT)

IEC6100-4-5 (Surge)

Noise (1m)

50- 60dB

Insulating resistance

Above 2M (500VDC)

Insulating intensity

(input, output to PE) 2820Vdc, leakage current lower than 3.5mA, no flashover in 1min

Surge protection

Meet the requirement of IEC60664-1class,endure surge of 1.2/50us+8/20us higher than 6KV/3KA

IP class

IP20

Battery configuration

Installation(dc)

+192/216/240Vdc ,-192/216/240Vdc

Battery type

Free Maintenance Lead Acid (Gel battery or Ni-Cd)

Long run

Battery to be connected external

Inbuilt battery

36pcs *7ah

36pcs *7ah

36pcs *9ah

72PCS*7ah

72pcs*9ah

*******

Connection

Bottom cable connection in front

Charger

20% Power capacity(Adjustable)

Physical

Unit Dimension

(Long-run)

390*850*977MM

 (W*D*H)

500×717×1150 MM (W*D*H)

720×900×1450 MM (W*D*H)

Unit Dimension

( Inbuilt batt.)

390*850*977MM

 (W*D*H)

500×717×1150

(W*D*H)

       500×717×1550

(W*D*H)

Weight (KG)

(Long -run)

110/130

130/150

152/172

160/190

160/190



240/280



260/300

Weight (KG)

(Inbuilt Batt.)

182/202

202/222

216/236

331/361

367/397



240/280



260/300

10kva and 15kva:inbuilt 36pcs 7ah

20kva:inbuilt 36pcs 9ah

(72pcs 7ah)

(72pcs 9ah)

Note:For 110/120/127Vac(L-N) ,60Hz 3phase, 10-40kva available;
