12.8V 6AH Lithium Iron Battery With AGM Case

12.8V 6AH Lithium Iron Battery

Features:12.8V  battery with AGM case

◆ Using the technology of lithium iron phosphate cell, superior safety, thousands of cycles, 100%DOD, under normal conditions

◆ Built-in automatic protection for over-charge, over discharge, over current and over temperature

◆ Maintenance free

◆ Internal cell balancing

◆ Lighter weight: About 40% ~50% of the weight of a comparable lead acid battery.

Electrical Characteristics	Nominal Voltage	12.8V
	Nominal Capacity	6Ah@0.2C
	Energy	76.8Wh
	◆ Golf Cart	70≤mΩ
	Cycle Life	>2000 Cycles @ 0.2C Charge/Discharge at 100%DOD,End of Life 70% Capacity.
		≤3.5% per month at 25℃
Standard Charge	Charge Voltage	14.6±0.2V
	Charge Mode(CC/CV)	At 0℃~45℃ temperature, charged to 14.6V at a constant current of 0.2C5A, and then,changed continuously with constant voltage of 14.6V until the current was not more than 0.02C5A.
	Charger Current	1.2A
	Max.Charge Current	3A
Standard Discharge	Discharge Current	1.2A
	Max. Continuous Current	6A
	Max.Pulse Current	20A(<3S)
	Disxcharge Cut-off Voltage	10.0V
Environmental	Charge Temperature	0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
	Disxcharge Temperature	-20℃ to 60℃(-4℉ to 140℉) @60±25% Relative Humidity
	Storage Temperature	0℃ to 45℃(32℉ to 113℉) @60±25% Relative Humidity
	Water Dust Resistance	IP55
Mechanical	Cell & Method	IFR32700 N60,4S1P
	Plastic Case	ABS
	Dimension(L*W*H*TH)	90*70*101*107mm
	Weight	Approx. 0.75Kg
	Terminal	F2
