Frequency Converter Power Supply Soucre 300 - 400Kva

Frequency Converter Power Supply Soucre 300 - 400Kva

Product Details:

Place of Origin: Shenzhen China
Brand Name: HRD/OEM
Certification: CE,ISO9001
Model Number: 8310,8315...83200,83300,83400

Payment & Shipping Terms:

Minimum Order Quantity: 5PCS
Price: 25000-28000USD
Packaging Details: Standard for Export
Delivery Time: 15-20days
Payment Terms: TT or LC at sight
Supply Ability: 120pcs/week
Price term: FOBSHENZHEN
Get Best Price Contact Now

Detail Information

Color: Gray Warranty: 18months Afert Shipment
Isolation: Input And Output Full Isolated CPU: 64-bit Microprocessor CPU
Capacity: 300-400kVA
High Light:

300Kva Frequency Converter

,

400Kva Frequency Converter

,

DSP Controlled Frequency Converter

Product Description

HRD 830 series Frequency Converter Power supply soucre 300-400Kva

DSP controlled, excellent perfance



Perfect Application
Aviation, Lab, Appliance Manufacturer, Medical Treatment, It Industry, Motor Manufacturer, scientific Research unit

Features & Benefits

Adopted 64-bit microprocessor CPU technology with excellent performance
50Hz 60Hz or 400Hz input frequency.
Output voltage (selectable).
40Hz to 499.9Hz output frequency range.
Programmable key lock setting output frequency.
Easy-to-read LEDs display output voltage, frequency, Ampere, Wattage & Power factor.
Stable true sine wave output.
Self Test at power on.
Galvanic isolation. No Harmonic Distortion.
PWM Technology minimizes the volume and weight.
IGBT technology increases the efficiency and reliability, eliminates the noise.
Capable of generating all kinds of frequencies used in all countries.
300% overload capability.
Breaker/alarm for overload, over temperature, and short circuit protection.
Suitable for use with RC, RL and non-linear loads.

Technical Specifications:



Model 83300 83400
Output Capacity (KVA) 300KVA 400KVA
Circuit mode 1GBT/PWM pulse width modulation mode.
AC Input Phase 3 Phase+N+PE
Voltage 380Vac +/-10% or 208Vac+/-10%
AC output Waveform Sine WAVE
Low level voltage 1 Phase voltage: 0-150V adjustable, 3 Phase voltage: 0-260V adjustable
High level voltage 1 Phase voltage: 0-300V adjustable, 3 Phase voltage: 0-520V adjustable
Frequency 40-499.9HZ continuously adjustable.(50HZ, 60HZ included.)
frequency
accuracy
≤ 0.01%
Highest Current High (A)240V 416 556
Highest Current Low (A)120V 832 1112
Machine performance Power Voltage accuracy <1%
Load accuracy <1%
Waveform (THD) <2%
Efficiency ≥90%
Response time ≤ 2ms
crest factor 3:1
Protection equipment With Over-voltage, over-current , over-temperature, overload, short circuit warning,input under voltage and other multiple protection
Display Display interface Digital LED display
Voltage 4 digits, digital voltmeter, resolution 0.1V
Current 4 digits, digital ammeter, resolution 0.1A
power 4 digits, digital watts table, resolution 0.1W
Frequency 4 digits, digital frequency table, resolution 0.1V
Other specifications Insulation Resistance DC500V ≥ 20MΩ
Pressure insulation AC 1800V 10mA/1 minutes
Cooling device Variable High speed cooling fan, Forced cold wind
Operating temperature -10 to 50 degrees.
Relative temperature 0-90% (Non-Condensation)
Altitude ≤ 1500m
Size(H*D*W)mm 1400*1100*800*2 1400*1100*800*2
Weight(KG) 2000 2500



Frequency Converter Power Supply Soucre 300 - 400Kva 0Frequency Converter Power Supply Soucre 300 - 400Kva 1
